Audio-Technica AT2020 BK Cardioid Condenser Microphone

Brand: Audio-Technica
  |
Stock Id: 480401

Audio-Technica AT2020 BK Cardioid Condenser Microphone

Brand: Audio-Technica
  |
Stock Id: 480401

The AT2020 has been created to bring professional-level audio capturing to anyone wanting to explore the world of sound recording. Whether it’s voiceovers, podcasting, singing vocals or live instrument recording, the A2020 is the critically acclaimed and iconic cardioid condenser designed around you — and your budget.

Audio-Technica’s stringent quality and consistency standards set the AT2020 apart from other mics in its class. Its low-mass diaphragm is custom-engineered for extended frequency response and superior transient response. With rugged construction for durable performance, the microphone offers a wide dynamic range and handles high SPLs with ease. The AT2020: the new standard for affordable side-address studio condensers.

A Condenser microphone such as the AT2020 contains a delicate diaphragm that captures the vibrations of the sounds you’re wanting to record. This diaphragm is so delicate that it requires powering through the XLR cable*, ensuring every aspect of your instrument or voice is captured in crisp detail.

Audio-Technica cardioid microphones have heart — figuratively and literally — thanks to the shape of the sound capture area. Cardioid microphones capture what’s in front of them in a rough heart shape, from the pinnacle of sound capture at the front of the microphone to the graduated capture off to the sides. This cardioid pattern improves isolation of any desired sound source for rich and accurate recording.

*XLR cable sold separately.

Features

  • AT2020 BK:
    • Microphone Type: Large Cardioid Condenser
    • Output Connector: Integral 3-pin XLRM-type
    • Phantom Power Requirements: 48V DC, 2 mA typical
    • Accessories Included: Stand mount for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; soft protective pouch

  • The price/performance standard in side-address studio condenser microphone technology
  • Ideal for project/home-studio applications
  • High SPL handling and wide dynamic range provide unmatched versatility
  • Custom-engineered low-mass diaphragm provides extended frequency response and superior transient response
  • Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
  • Pivoting, threaded stand mount attaches securely for easy and precise placement of the microphone
Microphones
ElementFixed-charge back plate, permanently polarized condenser
Polar PatternCardioid
Frequency Response20 - 20,000 Hz
Open Circuit Sensitivity-37 dB (14.1 mV) re 1V at 1 Pa
Maximum Input Sound Level144 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range124 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio74 dB, 1 kHz at 1 Pa
Phantom Power Requirements48V DC, 2 mA typical
Weight345g
Dimensions6.38" (162.0 mm) long, 2.05" (52.0 mm) maximum body diameter
Output ConnectorIntegral 3-pin XLRM-type
Accessories IncludedStand mount for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; soft protective pouch

Due to ongoing product development efforts, specifications are subject to change without notice.
